Grind Number: XA226/350-XA242/345-16+4
Hydraulic Roller Camshaft
Aggressive Street or Street/Strip Performance
Duration at .050": 226/242
116 Lobe Center Angle with a 112 Intake Centerline
Lift with 1.8 Rocker Arm Ratio: .630"/.621"
Recommended Displacement: 6.2 Liter Engines
Cylinder Heads: Gen 5 LT
Recommended Compression Ratio: 8.5-11:1
Recommended Headers: 1 3/4" - 1 7/8"
Recommended Stall Converter: 2800-3200
Recommended Rear Axle Ratio: 2.85-3.90
NOTE: Requires use of Cam Motion VVT Phaser Lock Block
The Gen 5 LT/CS 226/242 Centrifugal Supercharger Camshaft is designed for aggressive street performance in cars using 6.2 liter LT engines. The Gen 5 LT/CS 226/242 Centrifugal Supercharger Cam will have a slight performance idle and strong midrange to upper RPM power. This camshaft is designed to be used for vehicles equipped with headers, high flow exhaust and increased stall speed torque converter, high flow intake systems and increased rear axle ratios.
If you are looking for an aggressive performance cam that you can daily drive or race at the track, this camshaft is a great choice.
The TITAN series cams are designed with our renowned smooth cam lobe design that provides quiet valve train operation and excellent upper rpm stability. Cam Motion offers this cam in 5150 steel alloy camshaft cores.
NOTE: This camshaft is designed to be used with the phaser locked, or our VVT Phaser Delete Kit. Failure to lock the phaser or use our VVT Phaser Delete Kit when using this camshaft can result in serious engine damage! For more information, contact Cam Motion technical support.
•Cam Motion .660" lift Dual Valve Spring Kit
•Cam Motion 5/16" .080" Wall Hardened Chromoly Pushrods
•Cam Motion VVT Phaser Lock Block
•Cam Motion VVT Spring Lock Tool
